Lapp Kabel ÖLFLEX Heat 125 MC
Lapp Kabel ÖLFLEX Heat 125 MC
Benefits
- For safety in areas with high density of people
- Reduction of flame propagation, density and toxicity of smoke gases in event of fi re
- Minimises damage to buildings and equipment caused by the formation of toxic acid fumes in fi res
- Certified for maritime applications
Application range
- For the wiring and connection of lighting, heating appliances, control cabinets, and distributors in mechanical and plant engineering
- For use in traffic regulation systems and outdoors
- Coil winding, electromagnets, pumps, electrical systems
- Heat treatment plants, pressure die casting, heating and cooling technology
- For outdoor applications
Product features
- Fire behavior:
– Halogen-free (IEC 60754-1)
– No corrosive gases (IEC 60754-2)
– Low smoke density (IEC 61034-2)
– Flame-retardant (IEC 60332-1-2, NF C 32-070 (C1) and NF-F 16-101 (Class C))
– Low toxicity (EN 50305) - No fl ame-propagation according to
IEC 60332-3-22, IEC 60332-3-24 and
IEC 60332-3-25 (Flame spread on vertical cable bundle) - Oil-resistant acc. IEC 60227-1 (ST9) and EN 50264-1 (EM104)
- UV-resistant according to ISO 4892-2
- Ozone-resistant according to EN 50396
Norm references / Approvals
- GL – Germanischer Lloyd approved
- Based on EN 50525-3-21 and EN 50525-3-41
Product Make-up
- Fine-wire, tinned-copper conductor
- Electron beam cross-linked polyolefin copolymer insulation
- Cores twisted in layers
- Outer sheath: electron beam cross-linked polyolefin copolymer, black
Classification ETIM 5
- ETIM 5.0 Class-ID: EC001578
- ETIM 5.0 Class-Description: Flexible cable
Classification ETIM 6
- ETIM 6.0 Class-ID: EC001578
- ETIM 6.0 Class-Description: Flexible cable
Core identification code
- Up to 5 cores: colour-coded according to VDE 0293-308, refer to Appendix T9
- From 6 cores: black with white numbers
Conductor stranding
- Fine wire according to VDE 0295,
class 5/IEC 60228 class 5
Minimum bending radius
- Occasional flexing: 15 x outer diameter
- Fixed installation: 4 x outer diameter
Nominal voltage
- Up to 1.0mm² U0/U 300/500 V
From 1.5mm² U0/U 450/750 V - 0.6/1kV from 1.5 mm² in the case of fixed and protected installation
Test voltage
- 4000 V
Protective conductor
- G = with GN-YE protective conductor
- X = without protective conductor
Temperature range
- Occasional flexing: -35 °C to +120 °C
- Fixed installation: -55°C to +125°C
- Temporary (3.000h): up to +145°C
