Inverter Schneider Altivar Easy 610 75 kW/100 HP variable speed drive ATV610 – 75 kW/100 HP – 380…415 V – IP20 ATV610D75N4
Inverter Schneider Altivar Easy 610 75 kW/100 HP ATV610D75N4
Fitur
Altivar Easy 610 drives are part of the Easy line, the essential automation & control products from a worldwide leader.
When just enough is just right!
Fit for purpose products
- Integrated optimized EMC filter and DC choke, anti disturbance and harmonics without options
- Just enough I/O ports quantity, flexible integration into automation system
- Modbus communication embedded, Profibus DP as option
Easiness
- Compact size: simplicity of integration and reduction of the size of the enclosures
- Easy and quick installation, wiring and operation with the “Quick start“ User-friendly graphic display terminal: 6 or 20 integrated languages (English, Chinese…) depending on the model
- Duplicate the configuration by keypad from one powered-up drive on another powered-up drive
- Easy integration on an enclosure door: remote display terminal with a Ø 22mm quick-mounting system
- Colored control circuit terminals to avoid misuse7 pre-programmed function blocks cover 90% of the pump and fan applications
- Simply start menu cover the most frequently used parameters
Robustness in any situation (harsh environments…)
- Innovative cooling air flow separate from the printed circuit board to avoid dust and oil corrosion
- Electronic cards with protective coating
- Busbar plating to avoid chemical gas corrosion
- Improved insulation level in power part
- Operation temperature: – 10…+ 60°CIP40 protection level on top of the product
Availability
- Supported by the service of Schneider Electric, a worldwide leader in automation and control
- Wide availability throughout an extensive distribution network
Keuntungan
Altivar Easy 610 drives are entry-level products that are perfectly tailored to meet the specific requirements of emerging markets. In other words, they answer to the following challenges: fit for purpose at affordable price with no compromise on easiness, robustness, availability and services.
Altivar Easy 610 drives have been specifically designed for:
Domains & applications:
- Process & machine management / Pump & fan control: Air cooling system fan, Circulating pump, Cooling fan, Draught fan
- Building management: Fan, Circulating pump
Market Segments:
- Water & Wastewater: intake pump, boosting pump, lifting pump, aeration blower
- Oil & Gas: circulating pump, drain pump, oil transfer pump
Inverter Schneider Altivar Easy
| range of product | Easy Altivar 610 |
|---|---|
| product or component type | Variable speed drive |
| product specific application | Fan, pump, compressor, conveyor |
| device short name | ATV610 |
| variant | Standard version |
| product destination | Asynchronous motors |
| mounting mode | Cabinet mount |
| EMC filter | Integrated conforming to EN/IEC 61800-3 category C3 with 50 m |
| IP degree of protection | IP20 |
| type of cooling | Forced convection |
| supply frequency | 50…60 Hz +/-5 % |
| network number of phases | 3 phases |
| [Us] rated supply voltage | 380…460 V – 15…10 % |
| motor power kW | 75 kW for normal duty 55 kW for heavy duty |
| motor power hp | 100 hp for normal duty 75 hp for heavy duty |
| line current | 147.9 A at 380 V (normal duty) 130.2 A at 460 V (normal duty) 115.8 A at 380 V (heavy duty) 101.7 A at 460 V (heavy duty) |
| prospective line Isc | 22 kA |
| apparent power | 103.7 kVA at 460 V (normal duty) 81.0 kVA at 460 V (heavy duty) |
| continuous output current | 145 A at 2.5 kHz for normal duty 106 A at 2.5 kHz for heavy duty |
| maximum transient current | 160 A during 60 s (normal duty) 159 A during 60 s (heavy duty) |
| asynchronous motor control profile | Constant torque standard Optimized torque mode Variable torque standard |
| output frequency | 0.0001…0.5 kHz |
| nominal switching frequency | 2.5 kHz |
| switching frequency | 1…8 kHz adjustable |
| number of preset speeds | 16 preset speeds |
| communication port protocol | Modbus serial |
| option card | Slot A: communication card, Profibus DP V1 Slot A: digital or analog I/O extension card Slot A: relay output card |
